Model Net
weight
Power
supply
(DC)
Motor (watts) No load
absorption
Max.
Load
Max.
Pull
Line
speed
Rope
size
Chain
size
(mm)
YD-VC003 7 kg 12V or 24V 400W 30A 125kg 420kg 30m/min 12mm 6-7mm



1.Designed for traditonal rope and chain combination anchor rodes
2.line hauling from any direction
3.High quality finish on above deck components
4.Simplified through deck installation by modular design and precise alignment alignment of gearbox to the top works utilising marine-grade stainless  steel bolts.
5.Compact,reliable gearbox,made of corrosion resistant material
6.Heavy duty ,dual direction motors, designed for marine winches
7.Easily disassembled for servicing
8.Per set have the accessories of Hand-switches,Foot-switches,Solenoid,Handle
